Custom PVC wire harness high quality
Custom PVC wire harness high quality
Custom PVC wire harness high quality
Custom PVC wire harness high quality
Custom PVC wire harness high quality

Custom PVC wire harness high quality

$0.25-0.3 /Piece/Pieces

Min. Order:10 Piece/Pieces
Transportation:Ocean,Land,Air,Express
Port:Shenzhen
Contact Now
Product Description
Product Attributes
Packaging & Delivery
Product Description
Other information
Product Attributes

Brand: Suyi

Origin: China

Packaging & Delivery
Selling Units : Piece/Pieces
Package Type : cardboard box
Picture Example :
Download :

The file is encrypted. Please fill in the following information to continue accessing it

Inquire the password
JST XH2.54 Ribbon Cable Harness
Product Description
JST wiring harness

1. Product Overview

This wire harness consists of flat multi-conductor ribbon cable in white/light grey with blue printed stripe markings, terminated with two different connector types on each end: a white JST-compatible female socket housing on one end, and an exposed straight male pin header (through-hole or board-mount style) on the other end.

This asymmetric A-B configuration is specifically designed for board-to-board or board-to-device connections where one side plugs into a PCB-mounted female housing and the other side inserts directly into a through-hole pin header footprint or a mating female socket on a target board. This is a common wiring pattern used when connecting a daughter board, sensor module, or peripheral to a main controller board where the two connector types differ.

The blue printed stripe along the cable provides a consistent pin 1 orientation reference at both ends, ensuring correct polarity during assembly even when the two ends face different directions. The flat ribbon format keeps all conductors organized in a single plane, minimizing routing space and allowing the cable to fold neatly inside compact enclosures.

Multiple cables of the same specification are shown in the image, indicating batch production capability with consistent crimping and pin alignment across units. All contacts are machine-crimped and 100% continuity tested before shipment.

Key features:

Flat ribbon cable with blue stripe for reliable pin 1 orientation
Female JST-compatible socket on one end, exposed male pin header on the other
Asymmetric A-B connector configuration for mixed-footprint board connections
Machine crimping for consistent contact seating and pull-force
100% electrical continuity tested before shipment
RoHS compliant materials
OEM/ODM accepted, custom length and pin count available

2. Technical Specifications

Parameter Specification
Cable Type Flat ribbon, multi-conductor, grey/white PVC insulation
Stripe Marking Blue printed stripe, pin 1 orientation reference
End A Connector White JST-compatible female socket housing (XH/PH/ZH series)
End B Connector Straight male pin header, exposed pins (through-hole pitch)
Pitch Options 2.0 mm / 2.5 mm (confirm series at inquiry)
Pin Count 6P / 8P / 10P / 12P and above (custom available)
Wire Gauge AWG 26 / 28
Rated Voltage Up to 250V AC/DC
Rated Current Up to 3 A per contact (AWG 26)

3. Application Scenarios

Development Board Peripheral Connections This harness is widely used to connect Arduino, STM32, ESP32, and similar development boards to peripheral modules such as LCD displays, sensor breakout boards, and relay modules — where one board uses a JST female socket and the other exposes a standard 2.54 mm or 2.0 mm male pin header.

3D Printer Internal Wiring Multi-pin flat harnesses connecting control boards to LCD panels, filament runout sensors, and Z-axis probe modules in desktop 3D printers frequently use this socket-to-pin-header format, as the main board provides pin header rows while the peripheral provides a JST housing.

Industrial HMI & Control Modules Used inside compact industrial HMI panels and PLC expansion modules to route multi-channel signal lines between a logic board and a front-panel I/O connector block, where the two sides use different connector standards in a single assembly.

Battery Management Systems BMS balance harnesses with this socket-to-pin format connect individual cell tap wires from a female-terminated harness to a pin header input on the BMS PCB, allowing the harness to be unplugged from the cell stack without disturbing the BMS board.

Medical & Portable Instrument Assembly Used in handheld diagnostic and monitoring devices where the main PCB carries a male pin header and a plug-in sensor or display sub-assembly terminates with a JST female socket, enabling field replacement of sub-assemblies without soldering.

Consumer Electronics Manufacturing Internal signal harnesses connecting camera modules, display panels, and antenna boards to main PCBs in consumer devices commonly use this mixed-connector format when two different design teams specify different connector standards for each board.

4.FAQ

Q: Are you a trading company or a manufacturer/factory?
A: We are a factory.

Q: How do you guarantee product quality?
A: Quality is our lifeline. All raw materials we use are non-toxic and environmentally friendly, and we have a professional QA/QC team to ensure quality.

Q: Do you provide samples? Are they free or extra?
A: We provide free samples; you only need to pay for shipping.

Q: What is your delivery time?
A: Samples usually take 5-7 days, while mass production takes 10-15 working days, depending on the quantity.

Q: What is your minimum order quantity?
A: One piece is also our minimum order quantity.

Q: Do you accept OEM or ODM orders?
A: Yes, we accept OEM and ODM orders from our customers.
